Roof tiles 405w 425w solar panel
425w solar panel

Roof tiles 405w 425w solar panel

21.7% Max efficiency 405w 425w solar panel  0-3% power tolerance ja solar 410w panels.
  • Model:

    STM425-54M-T8S
  • Rated Power:

    425
  • Dimension:

    1722x1134x30mm
  • Weight:

    21.5Kg
  • No. Of Cells:

    108
  • Cell Type:

    210mm Perc
  • Module Color:

    sliver
  • Efficiency:

    21.7%
  • Certification:

    CE/TUV
  • Warranty:

    25 Years

Roof tiles 405w 425w solar panel

ja solar 410w panels with15 Years Warranty for Materials and Processing

shingled solar panels 410w with 25 Years Warranty for Extra Linear Power Output

Excellent low-light power generation effect, ensuring continuous output in cloudy,shading conditions.

Whole process of manufacturing adheres to the green concept, fluorine-free and low-lead.

Minimized micro-cracks with innovative non-destructive cutting Technology.

Selection of packaging materials with excellent sealing More advanced cell processing technology to reduce doping to ensure highly PID resistance.

Sand blowing test, salt mist test and ammonia test passed to adapt with harsh environments.

Mechanical performance up to 5400 Pa positive load and 2400 Pa.Negative load.





Cell Orientation 108(6x18)
Dimension 1722x1134x30mm
Weight 21.5kg
Glass 3.2mm AR Coating Tempered Glass
Frame  Anodized aluminum alloy frame
Junction Box  IP68,three diodes
Output Cable

 4mm3,300mm or1200mmLength

can be customized

Packaging 36pcs/pallet, 936pcs/40'HQ



Maximum Power(Pmax) 405w 410w 415w 420w 425w
Maximum Power Voltage(Vmp)    31.24V 31.43V 31.64V 31.83V 32.03V
Maximum Power Current(Imp) 12.97A  13.05A 13.13A 13.21A 13.29A
Open-circuit Voltage(Voc)      37.25V 37.5V 37.75V 37.00V 38.25V
Short-circuit Current(lsc)     13.96A 13.94A 14.02A 14.10A 14.18A
Module Efficiency(%)      20.70% 21.00% 21.3% 21.50% 21.70%



Maximum Power(Pmax) 302W 306W 310W 314W 318W
Maximum Power Voltage(Vmp) 29.2V 29.3V 29.6V 29.8V 30.00V
Maximum Power Current(Imp)  10.36A 10.42A 10.48A 10.54A 10.60A
Open-circuit Voltage(Voc) 35.10V 35.30V 35.50V 35.70V 35.90V
Short-circuit Current(lsc) 11.17A 11.24A 11.30A 11.36A 11.42A
Module Efficiency(%) 20.70% 21.00% 21.30% 21.50% 21.70%









-->
